Zyxel RGS200-12P Managed L2 Gigabit Ethernet (10/100/1000) Black Power over Ethernet (PoE)

Transparent IT Expo — Wednesday 1st March 2023

SKU: RGS200-12P-ZZ0101F Category:

Zyxel RGS200-12P Managed L2 Gigabit Ethernet (10/100/1000) Black Power over Ethernet (PoE)

* Images are for illustrative purposes only.
Share on facebook
Share on twitter
Share on whatsapp
Share on linkedin
Share on email

£954.65 £795.54 Ex. VAT

Out of stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

12-port GbE Managed PoE Switch

Along with the complete commercial product portfolio that offers customers with total network solutions, Zyxel introduces the new RGS Series of PoE switches with ruggedized design concepts to meet stringent outdoor or harsh network deployment scenarios. The special mechanism enables RGS200-12P to operate in outdoor, factory or other harsh environments for surveillance. In addition, it is also easy to manage RGS200-12P through a user-friendly Webbased GUI.

Benefits

Rugged and reliable design for harsh environments
Equipped with fanless and IP30 standard metal mechanism, the Zyxel RGS200-12P is able to deliver great thermal control and tolerate the dustiest deployments with ease, whether installed on a DIN rail or wall mounted for the most efficient use of cabinet space. Designed to handle temperatures ranging from -40°C to 75°C, the RGS200-12P can be placed in a variety of challenging environments and be adapted to broad range of field applications. When switching is applied normally in outdoor settings, ESD (electrostatic discharge), DC and Ethernet surge protection prevent the loss of business revenue and productivity due to damage or fatigue caused by power disturbances.

Quick failover for stable connectivity
When deployed in harsher conditions, such as factory or outdoor settings, the Zyxel RGS200-12P creates fault-tolerant networks with redundant ring technology and rapid self-recovery capability to prevent interruptions. In the event of downtime caused by a network error, the rapid failover will restore normal operation in less than 20 ms. The switch’s dual DC power inputs and reverse power protection feature ensure continuous uptime and reliable operation.

Trouble-free installation and easy extendibility
This rugged L2 Managed PoE switch comes with eight (8) 10/100/1000 Base-T copper PoE ports and four (4) 100/1000-Base-X SFP fiber interfaces. The switch also supports the 802.3at PoE plus standard, with each PoE port providing up to 30 W of power to efficiently accommodate the most power-hungry devices. The fiber uplink can extend the network to long-distance nodes up to 40 km (43,744 yards) away for added flexibility.


Feature Feature Value
Switch type Managed
Switch layer L2
Quality of Service (QoS) support Y
Web-based management Y
ARP inspection Y
System event log Y
MIB support RFC 2233 IF MIB, RFC1213 MIB II, RFC 1757 RMON 1/2/3/9, RFC1215, RFC1493, RFC 2674, LLDP-EXT-MED MIB
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 4
Fiber optic connector SFP
Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support N
Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T
Port mirroring Y
Full duplex Y
Flow control support Y
Link aggregation Y
Broadcast storm control Y
Rate limiting Y
Auto-negotiation Y
VLAN support Y
Virtual LAN features Tagged VLAN
Number of VLANs 1024
Fiber ethernet cabling technology 1000BASE-X
Transmission distance (max) 40 km
MAC address table 8000 entries
Switching capacity 24 Gbit/s
Throughput 17.86 Mpps
Store-and-forward Y
Number of queues 8
Jumbo frames support Y
Jumbo frames 9000
Packet buffer memory 0.5 MB
Access Control List (ACL) Y
IGMP snooping Y
Security algorithms 802.1x RADIUS,HTTPS,SNMP,SSH-2
MAC address filtering Y
SSH/SSL support Y
Authentication Guest VLAN,MAC-based authentication,Port-based authentication
Multicast support Y
Rack mounting Y
Product colour Black
Housing material Metal
International Protection (IP) code IP30
Wall mountable Y
DIN rail mounting Y
Firmware upgradeable Y
Buffer size 512 KB
Plug and Play Y
Mean time between failures (MTBF) 568430 h
DC input voltage 12 – 58 V
Power consumption (max) 255 W
Power over Ethernet (PoE) Y
Power over Ethernet plus (PoE+) ports quantity 8
Total Power over Ethernet (PoE) budget 240 W
Operating temperature (T-T) -40 – 75 °C
Storage temperature (T-T) -40 – 85 °C
Operating relative humidity (H-H) 5 – 95%
Storage relative humidity (H-H) 5 – 90%
Heat dissipation 86955 BTU/h
Width 77 mm
Depth 127.3 mm
Height 154 mm
Weight 1.45 kg
Wall mounting kit Y
Rack mount kit Y
Package width 133 mm
Package depth 192 mm
Package height 238 mm
Package weight 1.9 kg
Input voltage 12 – 58 V
Switch type

Managed

MAC address table

8000 entries

Weight

1.45 kg

DIN rail mounting

Y

Multicast support

Y

SSH/SSL support

Y

Rack mount kit

Y

Flow control support

Y

10G support

N

Fiber optic connector

SFP+

Port mirroring

Y

Wall mounting kit

Y

Web-based management

Y

Width

77 mm

Power over Ethernet (PoE)

Y

Wall mountable

Y

Rack mounting

Y

Authentication

Guest VLAN,MAC-based authentication,Port-based authentication

MAC address filtering

Y

Switch layer

L2+

Full duplex

Y

Number of VLANs

1024

VLAN support

Y

Rate limiting

Y

Switching capacity

24 Gbit/s
