SKU: PEX4M2E1 Category:

StarTech.com x4 PCI Express to M.2 PCIe SSD Adapter

* Images are for illustrative purposes only.

£25.26 £21.05 Ex. VAT

Availability: 129 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

Connect a PCIe M.2 SSD (NVMe or AHCI) to your computer through PCI Express for ultra-fast data access

Get ultra-fast data access by adding a PCIe M.2 SSD to your existing computer. This adapter lets you add a high-speed, 4-lane M.2 SSD (PCIe-based), such as a Samsung 950 Pro or Samsung SM 951, to a PC with an available x4 PCI Express expansion slot. You can mount the PCIe M.2 drive directly onto the adapter, giving you an easy and convenient way to improve your system performance and expand overall internal storage.

Boost your system speed and performance

The expansion card lets you take full advantage of the fast performance and compact size of PCIe M.2 internal solid-state drives. The adapter connects directly to your computer motherboard to support an M.2 PCIe-based SSD (NVMe or AHCI) through ultra-fast x4 PCIe. The adapter is compatible with PCIe 3.0 motherboards and is also backward compatible with PCIe 2.0 and PCIe 1.0. With the M.2 PCIe based drive in place, the adapter gives your computer a significant speed boost.

Supports PCIe M.2 SSDs

The adapter supports PCIe 3.0 x4 NVMe (M Key) and PCIe-AHCI M.2 SSDs including 2242, 2260, 2280, and 22110 drives. The expansion slot adapter supports the most common drive sizes including 110 mm, 80 mm, 60 mm and 42 mm.

Easy to install

The expansion card is equipped with a full-profile bracket and includes a half-height/low-profile bracket, for installation in small form-factor computers.

The PEX4M2E1 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

– Boost system speed and performance by adding a PCIe M.2 SSD to your PC
– Supports PCIe M.2 SSDs (NVMe and AHCI): 2242, 2260, 2280, and 22110 drives
– Compatible with PCIe 3.0 motherboards, and backward compatible with PCIe 2.0 and PCIe 1.0

– Boost system speed and performance by adding a PCIe M.2 SSD to your PC
– Supports PCIe M.2 SSDs (NVMe and AHCI): 2242, 2260, 2280, and 22110 drives
– Compatible with PCIe 3.0 motherboards, and backward compatible with PCIe 2.0 and PCIe 1.0
– Fast and easy setup with native OS support
– Installs into x4, x8 or x16 PCIe slots
– Equipped with a full-profile bracket, and includes a half-height/low-profile bracket for installation in small form-factor computers


Feature Feature Value
Host interface PCIe
Output interface M.2
Expansion card form factor Full-height / Low-profile
Internal Y
Product colour Red
LED indicators Y
Hot-swap N
RoHS compliance Y
Certification CE, FCC, REACH, TAA
Plug and Play Y
Operating temperature (T-T) 5 – 50 °C
Storage temperature (T-T) -25 – 70 °C
Operating relative humidity (H-H) 15 – 90%
Width 121 mm
Depth 179 mm
Height 184 mm
Weight 47 g
Mounting brackets included Y
Quick installation guide Y
Package width 15219 mm
Package depth 159 mm
Package height 46 mm
Package weight 151 g
Host interface

PCIe

Hot-swap

N

Weight

47 g

Width

121 mm

Mounting brackets included

Y
