Extend HDMI up to 330ft (100m) over CAT5/CAT6 cable with Power over Cable to Receiver

This HDBaseT extender Kit, extends HDMI up to 330 feet (100 Meters) over a single CAT5e or CAT6 cable. The extender supports Ultra HD and Full HD resolutions (4K / 1080p) with support for 3D and the accompanying 7.1 digital audio. For added versatility, both the transmitter and receiver can be powered by the same single power source using Power Over Cable (POC). The versatility of this video extender makes it an ideal solution for digital signage applications in large buildings such as commercial shopping centers, stadiums, schools, and hospitals.

What is HDBaseT?

HDBaseT is a standardized, zero latency, video distribution technology that’s revolutionizing HDMI distribution. HDBaseT uses an advanced method of modulation that enables you to distribute uncompressed HDMI audio and video, along with additional signals such as 100BaseT Ethernet, IR, RS-232 serial and power over cable.

Extend More than Video with HDBaseT

For greater versatility than a traditional HDMI extender or HDMI cabling alone, this HDBaseT extender offers HDMI + Power Over Cable in a single kit. The added benefit of power over cable means you’ll only need one power source at either side of your extension, great for extending to areas where power outlets may be limited.

Astonishing 4K picture quality from an impressive distance

With the A/V industry quickly adopting 4K as the new high-resolution video standard, long range video distribution can be a challenge with standard HDMI cables beginning signal degradation at 30 feet. With support for 4K you’ll be amazed at how HDBaseT maintains your Ultra HD picture quality, four times the resolution of high-definition 1080p, even at 130 feet away from your video source. Plus, because the extender supports High-Definition 1080p and lower resolutions at 330 feet away, you can comfortably use this extender to make any video source look great.

Hassle-free, Professional Installation with a Single Cable

This extender has been specially crafted for a smooth, tidy setup. HDBaseT technology allows for single cable installation, for seamless integration using existing CAT5e or CAT6 infrastructure, avoiding the hassle of running multiple cables, while reducing potential failure points. Plus, the added benefit of power over cable means you’ll only need one power source to power both your extender and receiver, great for extending to areas where power outlets may be limited. Mounting hardware is also included for both the extender and receiver for discrete, professional mounting.

The ST121HDBTPW is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.

The StarTech.com Advantage

– Extend video where power outlets are limited with HDBaseT offering power over cable that powers both the transmitter and receiver using a single power source at either side of the connection
– Maintains astonishing picture quality up to 115 ft. (35 m) away, with support for UltraHD 4K over non-proprietary CAT5e or CAT6 cabling
– Also supports HD video resolutions such as 1920×1200 or 1080p at distances up to 330 ft. (100m)


Feature Feature Value
Type AV transmitter & receiver
Maximum resolution 4096 x 2160 pixels
Cable types supported Cat5e,Cat6
Maximum transfer distance 100 m
Maximum refresh rate 60 Hz
Audio system Multichannel
Audio output channels 7.1 channels
LED indicators Status
Supported video modes 720p,1080p,2160p
Supported graphics resolutions 1280 x 720 (HD 720),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1600 (WQXGA),3840 x 2160,4096 x 2160
Material Aluminium
Daisy chain N
Rubber feet Y
Product colour Black
HDBaseT certified Y
RoHS compliance Y
Certification CE, FCC, REACH, TAA
RJ-45 input ports 1
RJ-45 output ports 1
HDMI in 1
Number of HDMI outputs 1
DC-in jack Y
AC input voltage 100-240 V
Operating voltage 12 V
Input current 0.5 A
Output current 1.5 A
Power consumption (typical) 18 W
External power adapter Y
Power plug type Type M
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -10 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 67 mm
Depth 80 mm
Height 25 mm
Weight 423 g
Package dimensions (WxDxH) 195 x 295 x 70 mm
Package width 196 mm
Package depth 295 mm
Package height 72 mm
Package weight 1.2 kg
AC adapter included Y
Cables included LAN (RJ-45)
Included power plug types AU,EU,NA,UK
Manual Y
Mounting brackets included Y
Grounding wire Y
Audio support Y
Type

AV transmitter & receiver

Cable types supported

Cat5e,Cat6

Maximum refresh rate

60 Hz

Material

Aluminium

Width

67 mm

Maximum resolution

4096 x 2160 pixels

Maximum transfer distance

100 m

Audio system

Multichannel

HDMI in

1

Weight

423 g

Mounting brackets included

Y
