Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps

SKU: ET91000SC2 Category: Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps

* Images are for illustrative purposes only.
Share on facebook
Share on twitter
Share on whatsapp
Share on linkedin
Share on email

£156.14 £130.12 Ex. VAT

Availability: 6 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multi Mode SC fiber

The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).

A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.

For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).

Backed by a 2-year warranty and free lifetime technical support.

The Advantage

– Link loss forwarding, remote status monitoring help ensure maximum up-time
– Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
– Rugged steel casing for durability in harsh environments

Feature Feature Value
Maximum data transfer rate 2000 Mbit/s
Ethernet interface type Gigabit Ethernet
Duplex system Full,Half
Fiber optic connector SC
Connectivity technology Wired
Ethernet LAN (RJ-45) ports 1
Maximum transfer distance 550 m
Wavelength 850 nm
Wavelength-division multiplexing (WDM) N
Fiber mode structure Multi-mode
Mean time between failures (MTBF) 65000 h
Internal N
Product colour Black
Housing material Steel
RoHS compliance Y
Certification CE, FCC
Input voltage 115 – 230 V
Input current 0.36 A
Output voltage 12 V
Output current 1.6 A
Power consumption (typical) 4 W
External power adapter Y
Power plug type Type M
Width 90 mm
Depth 150 mm
Height 25 mm
Weight 562 g
Operating temperature (T-T) 0 – 60 °C
Storage temperature (T-T) -10 – 70 °C
Operating relative humidity (H-H) 10 – 90%
Package width 135 mm
Package depth 203 mm
Package height 90 mm
Package weight 900 g
AC adapter included Y
Manual Y
Maximum data transfer rate

2000 Mbit/s

Fiber optic connector


Ethernet LAN (RJ-45) ports


Fiber mode structure



90 mm

Duplex system


Maximum transfer distance

550 m


562 g
