SKU: HSB1SATSASBA Category: 5.25 to 3.5 Hard Drive Hot Swap Bay – For 3.5″ SATA/SAS Drives – Trayless – Aluminum

* Images are for illustrative purposes only.

£37.85 £31.54 Ex. VAT

Availability: 7 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

Hot-swap drives with ease, using this trayless mobile backplane for desktop PCs or servers

This removable hard drive hot-swap bay makes it easy to swap 3.5” SATA or SAS drives in and out of your server or desktop computer, using an available 5.25” front drive bay. It features a trayless design that saves you installation time and enables you to insert or remove drives as needed, creating a convenient solution for drive maintenance and interchangeability of data between multiple systems.

Hot-swap drives easily

This hot-swap bay/mobile rack is ideal for IT professionals, such as system administrators or computer operators, for quickly swapping, replacing, or transporting drives between various systems and locations. With support for both SATA and SAS 3.5” drives, it saves valuable time in environments where storage drives need to be replaced or removed regularly, such as in server rooms and data centers.

Valuable drive protection

The hot-swap bay provides a protective backplane with a durable aluminum housing that offers ventilation to ensure proper air flow and heat dissipation. To safeguard your data, you can lock the drive bay door to prevent unauthorized access to your drive.

Fast data transfers

To maximize the speed and performance of your drives, the mobile rack supports SAS I and II and SATA I, II and III, providing data transfer speeds up to 6Gbps when paired with a compatible controller.

The HSB1SATSASBA is backed by a 2-year warranty and free lifetime technical support.

The Advantage

– Hot swap drives between systems, using a 3.5” SATA or SAS drive in a 5.25” front bay
– Durable aluminum construction
– Trayless design for ease of use

Feature Feature Value
Size 13.3 cm (5.25″)
Type Carrier panel
Number of HDDs supported 1
HDD size 3.5″
Maximum HDD capacity 10000 GB
HDD interface Serial ATA,Serial ATA II,Serial ATA III,Serial Attached SCSI (SAS)
Hot-swap Y
Data transfer rate 6 Gbit/s
LED indicators Activity,Power
Key lock Y
Product colour Black
Material Aluminium
Certification CE, FCC
RoHS compliance Y
Width 146 mm
Depth 179.4 mm
Height 42 mm
Weight 400 g
Package dimensions (WxDxH) 150 x 197 x 40 mm
Package weight 418 g
Cables included SATA
Screws included Y
Manual Y
Number of lock keys included 2 pc(s)
Operating temperature (T-T) 0 – 50 °C
Operating relative humidity (H-H) 5 – 85%
Storage relative humidity (H-H) 5 – 95%
