Dual Monitor Adapter | Windows | Thunderbolt 3 Compatible
This USB-C to DisplayPort MST Hub lets you connect two DisplayPort monitors to your USB Type-C Windows device, conveniently helping you to maximize your productivity.
Multitasking Made Easy
With devices becoming more portable than ever, you can be limited to fewer video outputs and confined to your small integrated screen. This multi-stream transport hub solves that problem by enabling you to connect two separate displays to your USB-C computer, making multitasking much easier.
Using this USB-C to dual DisplayPort monitor adapter, you can mirror your display onto additional monitors or stream independent content to each display, which makes it the ideal accessory for travel or hot-desking.
Astonishing Picture Quality
MST technology uses your existing video card to minimize the use of system resources, while delivering UHD 4K resolutions for two monitors or displays simultaneously. With support for HD 1080p and UHD 4K, the dual-monitor splitter is perfect for all high-resolution applications such as graphic design and CAD drawing.
Hassle-Free Setup
Multi-stream transport offers an easy setup, by natively working on any Windows device that supports DP Alt Mode over USB Type-C. This USB-C dual-monitor adapter is Thunderbolt 3 compatible, and offers plug-and-play installation with no drivers or software required. Additionally, this DP MST hub is powered by the USB-C port, meaning no external power cords are necessary.
MSTCDP122DP is backed by a StarTech.com 3-year warranty, and free lifetime technical support.
The StarTech.com Advantage
– Maximize your productivity by connecting two displays to your computer using the MST dual-monitor video splitter
– MST technology uses your existing video card to minimize the use of system resources
– Supports Ultra HD resolutions up to 4K
| Feature | Feature Value |
|---|---|
| DVI output | N |
| HDMI output | N |
| DisplayPort output | Y |
| Number of displays supported | 2 |
| USB connector type | USB Type-C |
| USB connector gender | Male |
| DisplayPort version | 1.2 |
| Maximum resolution | 3840 x 2160 pixels |
| Refresh rate at maximum resolution | 30 Hz |
| Supported graphics resolutions | 1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1440,2560 x 1600 (WQXGA),3840 x 2160 |
| Chipset | MegaChips – STDP4320, VIA/VLI – VL100 |
| RoHS compliance | Y |
| Certification | CE, FCC, REACH |
| Product colour | Black |
| Integrated USB cable | Y |
| USB cable length | 0.324 m |
| Windows operating systems supported | Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Operating temperature (T-T) | 5 – 35 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating relative humidity (H-H) | 50 – 90% |
| Width | 58 mm |
| Depth | 386 mm |
| Height | 14 mm |
| Weight | 44 g |
| Package width | 143 mm |
| Package depth | 172 mm |
| Package height | 32 mm |
| Package weight | 100 g |
| Quick installation guide | Y |
