2 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention

SKU: ICUSB2322F Category: 2 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention


Share on facebook
Share on twitter
Share on whatsapp
Share on reddit
Share on linkedin
Share on email

£40.10 £33.42 Ex. VAT

Availability: 12 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

The ICUSB2322F 2-Port USB to Serial RS232 Adapter Cable with FTDI chipset and COM Retention converts an available USB 1.1 or 2.0 port into 2 RS232 serial DB9 ports to connect, monitor and control your serial devices.

This compact adapter features COM retention, allowing the same COM port values to automatically be re-assigned to the port if the cable is disconnected and re-connected to the host computer, or if the system is rebooted. Unlike most USB-serial adapters, this one uses the FTDI chipset, which supports additional customization, advanced features, and compatibility not necessarily offered by other solutions.

This USB-serial adapter is compatible with a broad list of Operating Systems, including Windows®, Windows CE, Mac OS and Linux, making this product the perfect solution for integrating into mixed environments.

Backed by a 2-year warranty and free lifetime technical support.

The Advantage
– Simple installation and operation with COM port retention provides robust connectivity for serial devices
– Portable USB-Powered design requires no bulky power adapter or outlet
– The FTDI chipset is highly customizable and compatible, making it the ideal solution for any setup

Feature Feature Value
Connector 1 USB 2.0 A
Connector 2 DB9
Connector gender Male connector / Male connector
Cable length 2.133 m
Product colour Black
Housing material Plastic
Chipset FTDI – FT2232D
Data bits 7,8
Stop bits 1,2
Baud rate 921.6 Kbit/s
Parity bit Even,Mark,N,Odd,Space
FIFO (First In, First Out) 128 B
RoHS compliance Y
Certification CE, FCC
Compatible operating systems Windows 7 (32/64bit)/ Vista(32/64)/ XP(32/64)/ 2000/ CE(4.2+), Windows Server 2008 R2/ 2003(32/64), Mac OS 9.x, 10.x, Linux
Operating temperature (T-T) 0 – 55 °C
Storage temperature (T-T) -20 – 85 °C
Relative humidity 5 – 95%
Width 45 mm
Depth 2133 mm
Height 20 mm
Weight 159 g
Package width 145 mm
Package depth 175 mm
Package height 30 mm
Package weight 200 g
Quantity per pack 1 pc(s)
Manual Y
Drivers included Y

45 mm


FTDI – FT2232D

Cable length

2.133 m


159 g
