SP-8000-E3 Description
SP-8000-E3 Specifications
Design | |
---|---|
Form factor | Desktop |
Product colour | Black |
Power efficiency level | VI |
Features | |
Maximum resolution (HDMI) | 4096 x 2160 pixels |
Supported graphics resolutions | 1280 x 720 (HD 720),1920 x 1080 (HD 1080),4096 x 2160 |
Supported video modes | 720p,1080p |
Streaming capability | Yes |
Processor model | 820 |
Processor cores | 4 |
Graphics adapter | Adreno 530 |
Storage media | eMMC |
Processor family | Qualcomm Snapdragon |
RAM capacity | 4 GB |
Internal storage capacity | 16 GB |
Supported video streaming resolutions | 1280 × 720,1920 × 1080,4096 x 2160 |
Supported audio channels | 7.1 |
Antenna | |
Antenna type | Internal |
Network | |
Wi-Fi standards | Wi-Fi 5 (802.11ac) |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Networking standards | IEEE 802.11ac |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Dual-band | Yes |
Ports & interfaces | |
Interface | HDMI |
Number of HDMI outputs | 2 |
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Yes |
3.5 mm (1/8-inch) out | Yes |
HDMI version | 1.4b |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
HDMI input ports quantity | 1 |
Power over Ethernet plus (PoE+) ports quantity | 1 |
Power | |
Power source type | DC, PoE |
Input voltage | 100 – 240 V |
Input frequency | 50/60 Hz |
Output voltage | 12 V |
Output current | 2 A |
Power over Ethernet (PoE) | Yes |
Weight & dimensions | |
Width | 184.2 mm |
Depth | 86.2 mm |
Height | 26.3 mm |
Weight | 340 g |
Packaging content | |
AC adapter included | No |
Quick start guide | Yes |
Technical details | |
Sustainability certificates | RoHS |
