The Neomounts by Newstar desk mount, model NM-D750BLACK is a tilt-, swivel and rotatable desk mount for flat screens up to 32”. This mount is a great choice for space saving placement on desks using a desk clamp or grommet mount.
Neomounts by Newstars’ unique tilt (180°), rotate (180°) and swivel (360°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is easily height adjustable from 17 to 51 centimetres using a gas spring. Depth adjustable from 0 to 61 centimetres. A unique cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts by Newstar NM-D750BLACK has three pivot points and is suitable for screens up to 32″ (82 cm). The weight capacity of this product is 9 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75×75 or 100x100mm. Different hole patterns can be covered using Neomounts by Newstar VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Feature | Feature Value |
---|---|
Maximum weight capacity | 9 kg |
Maximum screen size compatibility | 81.3 cm (32″) |
Minimum screen size compatibility | 25.4 cm (10″) |
Suitable for | Computer monitor / TV |
Minimum VESA mount | 75 x 75 mm |
Maximum VESA mount | 100 x 100 mm |
Number of displays supported | 1 |
Mounting | Clamp/Bolt-through |
Panel mounting interface | 75 x 75,100 x 100 mm |
Height adjustment | Y |
Height adjustment range | 170 – 510 mm |
Depth adjustment range | 0 – 610 mm |
Tilt angle range | 0 – 180° |
Swivel angle | 360° |
Angle of rotation | 180° |
Product colour | Black |
Height | 510 mm |
Package width | 316 mm |
Package depth | 112 mm |
Package height | 485 mm |
Master (outer) case width | 39.5 cm |
Master (outer) case length | 12.5 cm |
Master (outer) case height | 23 cm |
Quantity per master (outer) case | 4 pc(s) |
Country of origin | China |
