Netgear M4300-52G-PoE+ 550W PSU Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Black 1U Power over Ethernet (PoE)

Transparent IT Expo — Wednesday 1st March 2023

SKU: GSM4352PA-100NES Category:

Netgear M4300-52G-PoE+ 550W PSU Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Black 1U Power over Ethernet (PoE)

* Images are for illustrative purposes only.
Share on facebook
Share on twitter
Share on whatsapp
Share on linkedin
Share on email

£3,082.84 £2,569.03 Ex. VAT

Out of stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

The NETGEAR M4300 Stackable Switch Series delivers L2/L3/L4 and IPv4/IPv6 cost-effective services for mid-enterprise edge with full PoE+ and SMB core deployments with unrivalled ease of use: 10 Gigabit models can seamlessly stack with 1 Gigabit models within the series, enabling spine and leaf line-rate stacking topologies. Non-stop forwarding (NSF) virtual chassis architectures provide advanced High Availability (HA) with hitless failover across the stack. Dual redundant, modular power supplies equipping full width models contribute to business continuity management. Layer 3 feature set includes static, dynamic and policy-based routing – as standard. Perfect for wireless access, unified communications and IP video, the NETGEAR M4300 Switch Series is also ready for the future, with Software-defined Network (SDN) and OpenFlow 1.3 enabled for your network.

Best-in-class stacking

– M4300 is flexible enough for mixed stacking between 10 Gigabit and 1 Gigabit models, using any 10G port with any media type (RJ45, SFP+, DAC cables)
– High-availability is another key differentiator for stackable solutions: in case of a master switch failure, NSF and hitless failover ensure the standby switch takes over while forwarding plane continues to forward traffic on the operational stack members without any service interruption

Higher flexibility

– Two half-width M4300 switches can be paired in a single rack space for redundant Top of Rack installations with Auto-iSCSI prioritization
– 10 Gigabit ports are all independent and 1G backward compatible for progressive transition to 10G speeds

Lower complexity

– Entire feature set including L2 switching (multi-tiered access control) and L3 routing (static, RIP, OSPF, VRRP, PIM, PBR) is available without license
– DHCP/BootP innovative auto-installation including firmware and configuration file upload automation

Investment protection

– Line-rate spine and leaf stacking topologies offer multiple possibilities in server rooms, in branch collapsed cores or at the edge of growing networks
– Even if an organization is not ready for SDN, OpenFlow support offers future-ready design for maximum investment protection

Secure services

– With successive tiering, the Authentication Manager allows for authentication methods per port for a tiered authentication based on configured time-outs
– With BYOD, tiered Dot1x -> MAB -> Captive Portal authentication is powerful and simple to implement with strict policies

Industry standard management

– Industry standard command line interface (CLI), functional NETGEAR web interface (GUI), SNMP, sFlow and RSPAN
– Single-pane-of-glass NMS300 management platform with centralized firmware updates and mass-configuration support

Industry leading warranty

– NETGEAR M4300 series is covered under NETGEAR ProSafe Lifetime Hardware Warranty
– 90 days of Technical Support via phone and email, Lifetime Technical Support through online chat and Lifetime Next Business Day hardware replacement


Feature Feature Value
Switch type Managed
Switch layer L2/L3/L4
Quality of Service (QoS) support Y
Web-based management Y
ARP inspection Y
Basic switching RJ-45 Ethernet ports quantity 48
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity 2
Fiber optic connector SFP+
Console port RJ-45/Mini-USB
USB 2.0 ports quantity 1
Networking standards IEEE 802.11ad,IEEE 802.11az,IEEE 802.3ad,IEEE 802.3az
10G support Y
Cable types supported Cat5,Cat5e,Cat6,Cat7,Fiber
Port mirroring Y
IP routing Y
Flow control support Y
Link aggregation Y
Rate limiting Y
Auto MDI/MDI-X Y
Spanning tree protocol Y
Auto-sensing Y
Auto-negotiation Y
VLAN support Y
Virtual LAN features Private VLAN
Number of VLANs 4000
Fiber ethernet cabling technology 10GBASE-LR,10GBASE-LRM,10GBASE-SR
MAC address table 16000 entries
Switching capacity 128 Gbit/s
Forwarding rate 357 Mpps
Store-and-forward Y
Number of static routes 64
Jumbo frames support Y
Jumbo frames 9000
Packet buffer memory 16 MB
DHCP features DHCP server,DHCP client
Access Control List (ACL) Y
IGMP snooping Y
Security algorithms HTTPS,SNMP,SSH
SSH/SSL support Y
BPDU filtering/protection Y
Multicast support Y
Number of multicast groups filtered 4000
Rack mounting Y
Stackable Y
Product colour Black
Form factor 1U
LED indicators Activity,Power,Speed
Safety CSA 22.2 #950, UL 1950)/cUL IEC 950/EN 60950
Electromagnetic compatibility CE, FCC 15 A, VCCI A, A EN 55022, (CISPR 22) A, EN 50082-1, EN 55024
Built-in processor Y
Processor frequency 800 MHz
Internal memory 1024 MB
Flash memory 256 MB
Noise level 39.8 dB
Mean time between failures (MTBF) 673207 h
Power supply included Y
Redundant power supply (RPS) support Y
Number of power supply units 1
AC input voltage 110 – 220 V
Power consumption (max) 865 W
Power over Ethernet (PoE) Y
Power over Ethernet (PoE) ports quantity 48
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 480 W
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 70 °C
Operating relative humidity (H-H) 0 – 90%
Storage relative humidity (H-H) 0 – 95%
Operating altitude 0 – 3000 m
Non-operating altitude 0 – 3000 m
Heat dissipation 207913 BTU/h
Width 440 mm
Depth 388 mm
Height 44 mm
Weight 6.67 kg
Cables included AC,LAN (RJ-45),Mini-USB
User guide Y
Rack mount kit Y
Rubber feet Y
Resource CD Y
Switch type

Managed

Flow control support

Y

Width

440 mm

Noise level

39.8 dB

Internal memory

1024 MB

Form factor

1U

Switching capacity

128 Gbit/s

Rate limiting

Y

Rack mount kit

Y

10G support

Y

Port mirroring

Y

Fiber optic connector

SFP+

USB 2.0 ports quantity

1

IP routing

Y

Weight

6.67 kg

Web-based management

Y

Power over Ethernet (PoE)

Y

Flash memory

256 MB

Processor frequency

800 MHz

Rack mounting

Y

Multicast support

Y

SSH/SSL support

Y

Forwarding rate

357 Mpps

Cable types supported

Cat5,Cat5e,Cat6,Cat7,Fiber

Switch layer

L2/L3/L4

Number of VLANs

4000

VLAN support

Y

MAC address table

16000 entries
