Instant Connectivity with Reliable Performance
The NETGEAR ProSAFE® Fast Ethernet Unmanaged Switch series helps businesses cost-effectively expand their network. These Unmanaged Fast Ethernet switches come in a wide range of models including desktop and rackmount form factors and 5 to 24 port configurations. The FS116P even supports PoE for low-cost PoE deployments. These switches are energy efficient, built to last, and rigorously tested to provide the reliability businesses need.
At Your Service
– Five, eight, or sixteen ports provide LAN access for many users. Every port supports up to 200 Mbps in dedicated bandwidth and traffic is forwarded flawlessly with automatic flow control.
Compact
– Solidly built in small sizes that are easy to position when space is at a premium. Ideal for conference rooms, class rooms, study groups or small offices. Place it on any flat surface or use the included wall mount kit to tuck it out of the way.
Simple To Use
– Once you connect the hardware, your switch is operating! Auto negotiation takes care of the speed and duplex, while Auto Uplink takes care of the MDI/MDI-X connection.
Quiet
– No fan means no noise, which helps maintain a peaceful atmosphere in your busy office.
| Feature | Feature Value |
|---|---|
| Switch type | Unmanaged |
| Switch layer | L2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 8 |
| Networking standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX |
| Full duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| MAC address table | 1024 entries |
| Store-and-forward | Y |
| Rack mounting | N |
| Product colour | Blue |
| LED indicators | Y |
| Buffer size | 96 KB |
| Mean time between failures (MTBF) | 4015496 h |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Power consumption (max) | 1 W |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -10 – 70 °C |
| Operating altitude | 0 – 3000 m |
| Non-operating altitude | 0 – 3000 m |
| Width | 158 mm |
| Depth | 102 mm |
| Height | 27 mm |
| Weight | 390 g |
