The NEC PA803UL Projector – combining laser, LCD and filter-free!
NEC has launched the world’s first filter-free laser projector using LCD technology.
With this unique combination, the brilliant colour brightness of LCD technology is coupled with the laser light source designed for long lasting operation. What’s more, with a completely sealed optical engine there is no filter needed at all. As result, service costs are dramatically reduced and with no dust to contaminate the LCD panels, you can enjoy consistently brilliant colour brightness. In addition, the PA series laser projector delivers incredible picture quality, impressive visualisation capabilities and powerful, cost-conscious installation opportunities.
The PA803UL projector is mainly targeting corporate and higher education users to equip their large meeting rooms, conference rooms and lecture halls.
– No filter service required – a completely sealed optical laser LCD engine allows a filter-free design. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget.
– No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
– Hassle-free remote adjustment – motorized lens shift, focus and zoom allows easy and flexible setup without the need for cumbersome physical access to the projector.
– Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, picture in picture, tiling, 3D support and camera based blending/stacking up to 4K.
– Cost conscious & powerful cabling – with just CAT6 network cabling, transfer content over up to 100m using HDBaseT connectivity standard. Supply multiple projectors with one source and benefit from the unique HDBaseT-out daisy-chain interface.
– Impress with brilliant colours & contrast – astound your audience as the projector processes a wider colour space with Rec2020 to Rec709 colour conversion and higher dynamic contrast supporting HDR10 standard via HDMI interface.
– Peace of mind copyright protected content – let the projector manage copyright protection and present 4k and Ultra HD Blu-ray content via the HDMI interface.
Feature | Feature Value |
---|---|
Projector brightness | 8000 ANSI lumens |
Projection technology | 3LCD |
Projector native resolution | WUXGA (1920×1200) |
Native aspect ratio | 16:10 |
Screen size compatibility | 1270 – 12700 mm (50 – 500″) |
Projection distance | 0.8 – 50.9 m |
Contrast ratio (dynamic) | 2500000:1 |
Keystone correction, horizontal | -40 – 40° |
Keystone correction, vertical | -40 – 40° |
Service life of lamp | 20000 h |
Focus | Auto |
Zoom capability | Y |
Zoom type | Auto |
Throw ratio | 1.30 – 3.02:1 |
Horizontal lens shift range | -20 – 20° |
Vertical lens shift range | -50 – 10° |
Full HD | Y |
3D | Y |
VGA (D-Sub) ports quantity | 1 |
HDMI ports quantity | 2 |
DVI port | N |
USB 2.0 ports quantity | 1 |
Audio (L,R) in | 1 |
Serial interface type | RS-232 |
DisplayPorts quantity | 1 |
HDBaseT port | Y |
Ethernet LAN | Y |
Wi-Fi | N |
Ethernet LAN (RJ-45) ports | 1 |
Noise level | 39 dB |
Noise level (economic mode) | 33 dB |
HDCP | Y |
On Screen Display (OSD) | Y |
Password protection | Y |
RoHS compliance | Y |
Product type | Desktop projector |
Product colour | White |
Ceiling mounting supported | Y |
Built-in display | Y |
Power source | AC |
Power consumption (typical) | 774 W |
Power consumption (standby) | 0.16 W |
Power consumption (network standby) | 0.7 W |
Power consumption (economy mode) | 592 W |
AC input voltage | 100 – 240 V |
AC input frequency | 50 – 60 Hz |
Operating temperature (T-T) | 5 – 40 °C |
Storage temperature (T-T) | -10 – 50 °C |
Operating relative humidity (H-H) | 20 – 80% |
Storage relative humidity (H-H) | 20 – 80% |
Safety | CE; EAC; ErP; TUEV Type Approved |
Weight | 18.2 kg |
Width | 580 mm |
Depth | 494 mm |
Height | 208 mm |
Handheld remote control | Y |
Remote control type | IR |
Cables included | AC |
Quick start guide | Y |
RS-232 ports | 1 |
