Your first choice for digital signage
For compelling Digital Signage results, NEC’s MultiSync V404 delivers professional capabilities with worry free operation yet at the lowest operational investment.
Convinicing visibility under common light conditions is guaranteed thanks to the combination of a brightness output of 500 cd/m² and an anti-glare surface. The modern and slim design is the perfect fit to complement the surrounding architecture as well as for integration into any application and environment. The wide range of connectivity options and compatibility with high resolution signals up to 4K/60Hz secure a futureproof investment providing a long-lasting success story. The Open Modular Intelligence (OMI) approach is the smartest way to deliver tailor-made Signage Solutions, where scalable computing power such as Raspberry Pi compute modules or OPS Slot-in PCs are seamlessly embedded into the display.
The 40” MultiSync ® V404 is the perfect choice for shorter viewing distances or big messages in retail environments, leisure and museum applications, quick service restaurants, for corporate information and all other public spaces.
| Feature | Feature Value |
|---|---|
| Display diagonal | 101.6 cm (40″) |
| Display type | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 440 cd/m² |
| HD type | Full HD |
| Touchscreen | Y |
| Response time | 8 ms |
| LED backlighting type | Edge-LED |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 10 |
| Contrast ratio (typical) | 4000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colors |
| Active display area (W x H) | 885.6 x 498.2 mm |
| Display diagonal (metric) | 101.6 cm |
| Horizontal scan range | 31.5 – 91.1 kHz |
| Vertical scan range | 24 – 85 Hz |
| Supported graphics resolutions | 640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1280 x 960,1360 x 768 (WXGA),1366 х 768,1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),1920 x 2160,3840 x 2160,4096 x 2160 |
| Supported video modes | 1080i,1080p |
| HDMI ports quantity | 2 |
| DVI port | Y |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 3 |
| USB port | Y |
| Ethernet LAN | Y |
| HDMI in | 2 |
| DVI-D ports quantity | 1 |
| DisplayPorts in | 2 |
| DisplayPorts out | 1 |
| USB ports quantity | 5 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 100 Mbit/s |
| RS-232 interface | Y |
| Card reader integrated | Y |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Design | Digital signage flat panel |
| Product colour | Black |
| VESA mounting | Y |
| Orientation | Horizontal/Vertical |
| Panel mounting interface | 300 x 300 mm |
| Bezel width (bottom) | 3.34 cm |
| Bezel width (side) | 3.34 cm |
| Bezel width (top) | 3.34 cm |
| Purpose | Retail |
| Multi-display supported | Y |
| Ambient light sensor | Y |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| International Protection (IP) code | IP5X |
| Power consumption (typical) | 75 W |
| Power consumption (standby) | 0.5 W |
| Energy efficiency class | B |
| Computer system | N |
| Video formats supported | FLV,H.264,MOV,MP4,MPEG1,MPEG2 |
| Audio formats supported | AAC,LC-AAC,LPCM,MP3,WAV |
| Image formats supported | JPG,PNG |
| Width | 954 mm |
| Depth | 78 mm |
| Height | 567 mm |
| Weight | 22.7 kg |
| Handheld remote control | Y |
| Remote control type | IR |
| Cables included | AC,DVI |
| Manual | Y |
| Quick start guide | Y |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| RoHS compliance | Y |
| Certification | C-tick; CE; EMC Class B; FCC; PSB; TÜV GS; UL/C-UL; CSA; VCCI |
| RS-232 input ports | 1 |
| Power management | Y |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| DVI input ports | 1 |
| Panel type | SPVA |
| Temperature indicator | Y |
| USB connector type | USB Type-A,USB Type-B |
