Lenovo X722 Ethernet 1000 Mbit/s Internal

Transparent IT Expo — Wednesday 1st March 2023

SKU: 7ZT7A00545 Category:

Lenovo X722 Ethernet 1000 Mbit/s Internal

* Images are for illustrative purposes only.
Share on facebook
Share on twitter
Share on whatsapp
Share on linkedin
Share on email

£94.56 £78.80 Ex. VAT

Availability: 45 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 “Lewisburg” PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.

ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.

The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.


Feature Feature Value
Connectivity technology Wired
Host interface PCI Express
Interface Ethernet
Ethernet LAN (RJ-45) ports 4
Maximum data transfer rate 1000 Mbit/s
Networking standards IEEE 802.1Q,IEEE 802.1Qbg,IEEE 802.1p,IEEE 802.3ad,IEEE 802.3x
Ethernet LAN data rates 10,100,1000 Mbit/s
Security algorithms SNMP
Flow control support Y
Jumbo frames support Y
Quality of Service (QoS) support Y
VLAN tagging Y
Jumbo frames 9728
Internal Y
Product colour Green
RoHS compliance Y
Certification UL recognized to UL60950-1 2nd EditionnFCC Rules, Part 15, Class AnAustralian EMC Framework (RCM)nJapan VCCI, Class AnIndustry Canada, ICES-003, Class AnEU (CE Mark)nKorea KC-RRA, Class A
Compatible products SR630nSR650nSR850nSR860nSR950
Linux operating systems supported Red Hat Enterprise Linux WS 6.0,Red Hat Enterprise Linux WS 7.0,openSUSE 11.3,openSUSE 11.4,openSUSE 12.1,openSUSE 12.2
Other operating systems supported VMware vSphere ESXi
Server operating systems supported Windows Server 2012 R2,Windows Server 2012 R2 x64,Windows Server 2016
Chipset Intel C624
Number of VLANs 4096
PCI-SIG* SR-IOV Capable Y
Receive Side Scaling (RSS) Y
Interface

Ethernet

Maximum data transfer rate

1000 Mbit/s

Ethernet LAN data rates

10,100,1000 Mbit/s

Flow control support

Y

Number of VLANs

4096

Host interface

PCI Express

Ethernet LAN (RJ-45) ports

4

VLAN tagging

Y

Chipset

Intel C624
