Intel® Optane™ Memory Supported.
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.
Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.
| Feature | Feature Value |
|---|---|
| Processor frequency | 2.40 GHz |
| Processor family | 7th gen Intel® Core™ i3 |
| Processor model | i3-7100U |
| Processor cores | 2 |
| Number of processors installed | 1 |
| Processor socket | BGA 1356 |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Processor threads | 4 |
| System bus rate | 4 GT/s |
| Bus type | OPI |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Kaby Lake |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-down frequency | 800 MHz |
| Tjunction | 100 °C |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 12 |
| PCI Express configurations | 1×2+2×1,1×4,2×2,4×1 |
| Stepping | H0 |
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR3L,DDR4-SDRAM,LPDDR3-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| ECC supported by processor | N |
| Internal memory | 4 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 2x DIMM |
| Number of DIMM slots | 2 |
| Memory clock speed | 2400 MHz |
| ECC | N |
| Memory channels | Dual |
| Total storage capacity | 1000 GB |
| Card reader integrated | Y |
| Storage media | HDD |
| Number of storage drives installed | 1 |
| Number of HDDs installed | 1 |
| HDD capacity | 1000 GB |
| HDD interface | Serial ATA III |
| Intel® Optane™ Memory module installed | Y |
| Compatible memory cards | SDXC |
| Discrete graphics adapter | N |
| On-board graphics adapter | Y |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter model | Intel® HD Graphics 620 |
| On-board graphics adapter family | Intel® HD Graphics |
| On-board graphics adapter base frequency | 300 MHz |
| On-board graphics adapter dynamic frequency (max) | 1000 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter ID | 0x5916 |
| Optical drive type | N |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Bluetooth | Y |
| Bluetooth version | 4.2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DVI port | N |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | N |
| Combo headphone/mic port | Y |
| DC-in jack | Y |
| M.2 card slot (storage) | 22×42/80 |
| Total number of SATA connectors | 2 |
| Number of SATA III connectors | 2 |
| Product colour | Black,Grey |
| Chassis type | Nettop |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product type | Mini PC |
| Market positioning | Business |
| Motherboard form factor | UCFF |
| Compatible processor series | Intel® Core™ i3 |
| Audio output channels | 7.1 channels |
| BIOS type | EEPROM |
| BIOS memory size | 64 Mbit |
| Trusted Platform Module (TPM) | N |
| Number of displays supported | 3 |
| ARK ID | 126288 |
| Consumer infrared Rx sensor | Y |
| Removable memory card slot | Micro SDXC with UHS-I support |
| Harmonized System (HS) code | 8471500150 |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Compatible operating systems | Windows 10, 64-bit* |
| Intel® vPro™ Technology | N |
| Intel® Small Business Advantage (Intel® SBA) | Y |
| Intel® Wireless Display (Intel® WiDi) | Y |
| Intel® High Definition Audio (Intel® HD Audio) | Y |
| Intel 64 | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Embedded options available | N |
| Intel® InTru™ 3D Technology | Y |
| Intel® Insider™ | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel Clear Video Technology | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel TSX-NI | N |
| Idle States | Y |
| Thermal Monitoring Technologies | Y |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Secure Key | Y |
| Intel® OS Guard | Y |
| Intel Trusted Execution Technology | N |
| Execute Disable Bit | Y |
| Intel Flex Memory Access | Y |
| Intel Enhanced Halt State | Y |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Processor package size | 42 x 24 mm |
| Supported instruction sets | AVX 2.0,SSE4.2 |
| Processor code | SR2ZW |
| CPU configuration (max) | 1 |
| Graphics & IMC lithography | 14 nm |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Rapid Storage Technology | Y |
| Processor ARK ID | 95442 |
| Intel® Optane™ Memory Ready | Y |
| Intel® Platform Trust Technology (Intel® PTT) | Y |
| Intel® Smart Response Technology | Y |
| Intel® Turbo Boost Technology | N |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel® My WiFi Technology (Intel® MWT) | Y |
| Conflict Free processor | Y |
| Power supply input voltage | 12 – 19 V |
| DC input voltage | 12-19 DC |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| RoHS compliance | Y |
| Certification | IEC 60950-1, UL 60950-1, EN 60950-1, CAN/CSA-C22.2 No. 60950-1, CISPR 32, FCC CFR title 47, chapter I, part 15, subparts B, C, E, ICES-003, EN 55032, EN 55024, ETSI EN 300 328, ETSI EN 301 489-1, ETSI EN 301 489-17, ETSI EN 301 893, EN 62311, AS/NZS 2772.2, AS/NZS 4268, VCCI V-2, V-3, V-4, KN-32, KN-24, CNS 13438, WEEE |
| Width | 115 mm |
| Depth | 111 mm |
| Height | 51 mm |
| Display included | N |
| Manual | Y |
| Form factor | UCFF (4″ x 4″) |
| Number of SATA connectors | 2 |
| USB ports quantity | 6 |
| Graphics output | HDMI 2.0a; USB-C (DP1.2) |
| Product family | Intel NUC |
| Status | Launched |
| Pre-installed operating system | Windows 10, 64-bit* |
| Intel® vPro™ Platform Eligibility | N |
| Processor included | Intel® Core™ i3-7100U Processor (3M Cache, 2.40 GHz) |
