Configure Your Ideal Gaming Rig
The Intel® Z390 chipset paired with an Intel® Core™ i9-9900K processor are fast and powerful out of the box—and still let you custom tune for even higher performance.
| Feature | Feature Value |
|---|---|
| Processor family | 9th gen Intel® Core™ i9 |
| Processor frequency | 3.6 GHz |
| Processor cores | 8 |
| Processor socket | LGA 1151 (Socket H4) |
| Component for | PC |
| Processor lithography | 14 nm |
| Box | Y |
| Processor model | i9-9900K |
| Processor threads | 16 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor series | Intel Core i9-9900 Desktop Series |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| Stepping | P0 |
| Processor boost frequency | 5 GHz |
| Bus type | DMI3 |
| Processor codename | Coffee Lake |
| Memory bandwidth supported by processor (max) | 41.6 GB/s |
| Processor code | SRELS |
| Processor ARK ID | 186605 |
| Memory channels | Dual |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| ECC | N |
| On-board graphics adapter | Y |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel® UHD Graphics 630 |
| Discrete graphics adapter model | Not available |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter outputs supported | DisplayPort,Embedded DisplayPort (eDP),HDMI |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1200 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter 4K support | Y |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.5 |
| On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (eDP – Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics adapter refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics adapter ID | 0x3E98 |
| Thermal Design Power (TDP) | 95 W |
| Execute Disable Bit | Y |
| Idle States | Y |
| Thermal Monitoring Technologies | Y |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1×16,1×8+2×4,2×8 |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Thermal solution specification | PCG 2015D |
| PCI Express CEM revision | 3.0 |
| Market segment | DT |
| Harmonized System (HS) code | 8542310001 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® vPro™ Technology | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel® InTru™ 3D Technology | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Smart Cache | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Trusted Execution Technology | Y |
| Intel® Memory Protection Extensions (Intel® MPX) | Y |
| Intel Enhanced Halt State | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® Secure Key | Y |
| Intel TSX-NI | Y |
| Intel Stable Image Platform Program (SIPP) | Y |
| Intel® OS Guard | Y |
| Intel Clear Video Technology | Y |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Intel 64 | Y |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel TSX-NI version | 1.00 |
| Intel® Optane™ Memory Ready | Y |
| Intel® Boot Guard | Y |
| Tjunction | 100 °C |
| Processor cache | 16384 KB |
| Product type | Processor |
| Maximum graphics adapter memory | 64 GB |
| Processor package size | 37.5 x 37.5 mm |
| Maximum internal memory | 65536 MB |
| Generation | 9th Generation |
| Intel® vPro™ Platform Eligibility | Y |
| Bus bandwidth | 8 |
| Bus type units | GT/s |
| Launch date | Q4’18 |
| Maximum resolution & refresh rate (DisplayPort) | 4096×[email protected] |
| Maximum resolution & refresh rate (HDMI) | 4096×[email protected] |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096×[email protected] |
| Status | Launched |
| Maximum memory | 128 GB |
| Processor brand name | 9th Gen Intel Core i9n9th Gen Intel Core i9 Processor |
| Last change | 63903513 |
| Product family | Intel Core Processors |
| Bus speed | 8 GT/s |
| Processor ID | 0x3E98 |
