SKU: BX8071512900KF Category:

Intel Core i9-12900KF processor 30 MB Smart Cache Box

Intel® Core™ i9-12900KF Processor (30M Cache, up to 5.20 GHz)

* Images are for illustrative purposes only.

£361.86 £301.55 Ex. VAT

Free UK Shipping Available*

Availability: 3 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

Intel® Virtualization Technology for Directed I/O (VT-d) Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments. Intel® Virtualization Technology (VT-x) Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions. Intel® 64 Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory. Cache CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache. Intel® AES New Instructions Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption. Idle States Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states. Intel® Turbo Boost Technology Intel® Turbo Boost Technology dynamically increases the processor’s frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t. Max Turbo Frequency Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second. Execute Disable Bit Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network. Intel® Hyper-Threading Technology Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner. Instruction Set An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with. Intel® VT-x with Extended Page Tables (EPT) Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management. Intel® Optane™ Memory Supported Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration. Enhanced Intel SpeedStep® Technology Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery. Secure Key Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms. Intel® Speed Shift Technology Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency. Intel® Deep Learning Boost (Intel® DL Boost) A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations. Instruction Set Extensions Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions). Intel® Turbo Boost Max Technology 3.0 Frequency Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom. Intel® Turbo Boost Max Technology 3.0 frequency is the clock frequency of the CPU when running in this mode. Intel® Turbo Boost Max Technology 3.0 Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom. Thermal Monitoring Technologies Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core’s temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits. Intel® Volume Management Device (VMD) Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives. Intel® Gaussian & Neural Accelerator Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload. Mode-based Execute Control (MBE) Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code. Intel® Boot Guard Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks. Intel® Control-Flow Enforcement Technology CET – Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.


Processor
Processor generation 12th gen Intel® Core™ i9
Processor manufacturer Intel
Processor codename Alder Lake
Memory bandwidth supported by processor (max) 76.8 GB/s
Processor cache 30 MB
Processor model i9-12900KF
Processor threads 24
Processor operating modes 64-bit
Processor boost frequency 5.2 GHz
Bus type DMI4
Component for PC
Processor family Intel Core i9
Processor cores 16
Box Yes
Processor socket LGA 1700
Processor cache type Smart Cache
Performance cores 8
Efficient cores 8
Performance-core boost frequency 5.1 GHz
Performance-core base frequency 3.2 GHz
Efficient-core boost frequency 3.9 GHz
Efficient-core base frequency 2.4 GHz
Processor base power 125 W
Maximum turbo power 241 W
Maximum number of DMI lanes 8
Memory
Maximum internal memory supported by processor 128 GB
Memory types supported by processor DDR4-SDRAM,DDR5-SDRAM
Memory bandwidth supported by processor (max) 76.8 GB/s
Memory channels Dual-channel
Memory bandwidth (max) 76.8 GB/s
Graphics
Discrete graphics adapter No
On-board graphics adapter model Not available
On-board graphics adapter No
Discrete graphics adapter model Not available
Technical details
Thermal solution specification PCG 2020A
Intel® Secure Key Yes
Thermal Monitoring Technologies Yes
Intel® Turbo Boost Technology 2.0
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Idle States Yes
Execute Disable Bit Yes
Enhanced Intel SpeedStep Technology Yes
PCI Express slots version 5.0,4.0
PCI Express configurations 1×16+1×4,2×8+1×4
Supported instruction sets SSE4.1,SSE4.2,AVX 2.0
Scalability 1S
Intel VT-x with Extended Page Tables (EPT) Yes
Embedded options available No
CPU configuration (max) 1
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel 64 Yes
Status Launched
Market segment Desktop
Launch date Q4’21
Intel Virtualization Technology (VT-x) Yes
Processor cache type Smart Cache
Target market Gaming, Content Creation
Features
Maximum number of PCI Express lanes 20
Processor package size 45 x 37.5 mm
Thermal solution specification PCG 2020A
Thermal Monitoring Technologies Yes
Idle States Yes
Execute Disable Bit Yes
PCI Express slots version 5.0,4.0
PCI Express configurations 1×16+1×4,2×8+1×4
Supported instruction sets SSE4.1,SSE4.2,AVX 2.0
Scalability 1S
Embedded options available No
CPU configuration (max) 1
Market segment Desktop
Harmonized System (HS) code 8542310001
Export Control Classification Number (ECCN) 5A992CN3
Commodity Classification Automated Tracking System (CCATS) G167599
Use conditions PC/Client/Tablet
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel 64 Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel® Speed Shift Technology Yes
Intel® Optane™ Memory Ready Yes
Intel® OS Guard Yes
Intel® Secure Key Yes
Intel® Turbo Boost Technology 2.0
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel Virtualization Technology (VT-x) Yes
Intel® Boot Guard Yes
Intel® Volume Management Device (VMD) Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Mode-based Execute Control (MBE) Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.2 GHz
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Operational conditions
Tjunction 100 °C
Packaging data
Package type Retail box
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
Maximum internal memory 128 GB
CPU configuration (max) 1

Product Family: Core

Weight 90.5000 kg
Brand

EAN

5032037234221

UNSPSC

43201503
