The Time for a Faster, Smarter PC is Now.
Introducing a new tier of PCs, featuring even more powerful performance for seamless computing at home and on-the-go. Work untethered with amazing battery life and experience smooth streaming and brilliant HD entertainment with immersive, full-screen 4K and 360 viewing.
The Speed You Need
Equipped with rapid responsiveness, the 7th generation Intel® Core™ processor has the power and speed to keep up with your demands. Open files and programs quickly, plus seamlessly switch between applications and web pages without delay.
Immersive Entertainment
Experience ultra high-definition content with the clarity and sharpness of 4K resolution.1 Featuring 4x more pixels than full HD screens, you’ll get crisper, clearer images for an immersive viewing like never before.
Hassle Free
Today’s PCs are more hassle-free than ever – log in quickly and easily with facial recognition technology, get 0.5 second wake, and never feel weighed down with new razor-thin devices.
| Feature | Feature Value |
|---|---|
| Processor family | 7th gen Intel® Core™ i3 |
| Processor frequency | 4 GHz |
| Processor cores | 2 |
| Processor socket | LGA 1151 (Socket H4) |
| Component for | PC |
| Processor lithography | 14 nm |
| Box | Y |
| Processor model | i3-7300 |
| Processor threads | 4 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor series | Intel Core i3-7300 Desktop Series |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Stepping | S0 |
| Bus type | DMI3 |
| Processor codename | Kaby Lake |
| Processor code | SR359 |
| Processor ARK ID | 97458 |
| Memory channels | Dual |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| Memory voltage supported by processor | 1.35 V |
| ECC | Y |
| On-board graphics adapter | Y |
| On-board graphics adapter model | Intel® HD Graphics 630 |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter outputs supported | DisplayPort,Embedded DisplayPort (eDP),HDMI |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1150 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter 4K support | Y |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (eDP – Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics adapter refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics adapter ID | 0x5912 |
| Thermal Design Power (TDP) | 51 W |
| Execute Disable Bit | Y |
| Idle States | Y |
| Thermal Monitoring Technologies | Y |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1×16,1×8+2×4,2×8 |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Thermal solution specification | PCG 2015C |
| PCI Express CEM revision | 3.0 |
| Market segment | DT |
| Harmonized System (HS) code | 8542310001 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Turbo Boost Technology | N |
| Intel® vPro™ Technology | N |
| Intel® Quick Sync Video Technology | Y |
| Intel® InTru™ 3D Technology | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Trusted Execution Technology | N |
| Intel® Memory Protection Extensions (Intel® MPX) | Y |
| Intel Enhanced Halt State | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® Secure Key | Y |
| Intel TSX-NI | N |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel® OS Guard | Y |
| Intel Clear Video Technology | Y |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Intel 64 | Y |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel TSX-NI version | 0.00 |
| Conflict Free processor | Y |
| Intel® Optane™ Memory Ready | Y |
| Intel® Boot Guard | Y |
| Tjunction | 100 °C |
| Processor cache | 4096 KB |
| Product type | Processor |
| Maximum graphics adapter memory | 64 GB |
| Processor package size | 37.5 x 37.5 mm |
| Maximum internal memory | 65536 MB |
| Video decoding | Y |
| Generation | 7th Generation |
| Intel® vPro™ Platform Eligibility | N |
| Bus bandwidth | 8 |
| Bus type units | GT/s |
| Launch date | Q1’17 |
| Maximum resolution & refresh rate (DisplayPort) | 4096×[email protected] |
| Maximum resolution & refresh rate (HDMI) | 4096×[email protected] |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096×[email protected] |
| Status | Launched |
| Maximum memory | 64 GB |
| Processor brand name | 7th Gen Intel Core i3 processors |
| Last change | 63903513 |
| Product family | 7th Generation Intel Core i3 Processors |
| Bus speed | 8 GT/s |
| Processor ID | 0x5912 |
