Honeywell Solaris 7980g Fixed bar code reader 1D/2D Black

Manufacturer: | Honeywell |
Category: | Printers & Scanners |
Sub-Category: | Barcode Readers |
SKU: | 7980G-2USBX-0 |
EAN: | 5712505805176 |
Description
With its compact, modern design and powerful imaging capabilities, the Solaris 7980g fits easily into existing enclosures used in high-volume retail checkout environments such as convenience, drug, specialty, liquor and grocery stores. And you can buy the 7980g device as an omnidirectional 1D scanner. Then affordably upgrade it to a full 2D area-imager when you’re ready.
Powerful Imaging Capabilities
Exceptional scanning performance on 1D and 2D barcodes, plus the ability to read smartphone screens, digital wallets and printed identification cards.
Soft, White LED Illumination
Eliminates glare without compromising performance.
Simple to Install
Compatible with most point-of-sale systems. Features integrated EAS, power-over-USB, and an auxiliary USB port for scanner connectivity.
Easy to Use
Features a capacitive touch button and intuitive LED indicators that face the user. And you can connect a handheld scanner via a multi-function USB auxiliary port.
Draws Power From the Host
Draws power directly through USB, eliminating the need for an additional power supply and cabling.
Specifications
Scanning | |
---|---|
Type | Fixed bar code reader |
Linear (1D) barcodes supported | Codabar,Code 11,Code 128,Code 32,Code 39,Code 93,EAN-13,EAN-8,Intelligent Mail,JAN,MSI,PLANET,POSTNET,Plessey,Telepen,Trioptic,U.P.C. |
2D (matrix & stacked) barcodes supported | Aztec Code,Codablock,Code 49,Data Matrix,Han Xin,MaxiCode,Micro QR Code,PDF417,QR Code |
Yaw reading angle | -75 – 75° |
Scanner type | 1D/2D |
Pitch reading angle | -65 – 65° |
Maximum scan area | 0 x 190 mm |
Light levels (direct sunlight) | 0 – 100000 lx |
Ports & interfaces | |
Connectivity technology | Wired |
USB version | 2.0 |
USB 2.0 ports quantity | 1 |
Standard interfaces | Keyboard wedge,RS-232,USB |
Performance | |
Programming function | Yes |
Light levels (direct sunlight) | 0 – 100000 lx |
Design | |
Type | Fixed bar code reader |
RoHS compliance | Yes |
LED indicators | Status |
International Protection (IP) code | IPX5 |
Product colour | Black |
Certification | CE, UL, RoHS |
Power | |
Power consumption | 400 mA |
Power source type | AC,DC |
Input frequency | 50/60 Hz |
Input voltage | 100 – 240 V |
AC adapter output voltage | 5 – 5.2 V |
Weight & dimensions | |
Width | 152 mm |
Depth | 85 mm |
Height | 148 mm |
Weight | 539 g |
Technical details | |
Type | Fixed bar code reader |
RoHS compliance | Yes |
LED indicators | Status |
USB 2.0 ports quantity | 1 |
International Protection (IP) code | IPX5 |
Product colour | Black |
Certification | CE, UL, RoHS |
Programming function | Yes |
Operational conditions | |
Storage temperature (T-T) | -20 – 60 °C |
Operating temperature (T-T) | 0 – 40 °C |
Operating relative humidity (H-H) | 5 – 95% |
Light levels (direct sunlight) | 0 – 100000 lx |
Other features | |
USB 2.0 ports quantity | 1 |
