Performance |
Infrared (IR) cut-off filter |
Yes |
Type |
IP security camera |
Connectivity technology |
Wired |
PTZ control |
Yes |
Placement supported |
Outdoor |
Wide Dynamic Range (WDR) |
Yes |
Day/night mode |
Yes |
Alarm input/output |
Yes |
Design |
IK code |
IK10 |
Form factor |
Dome |
Product colour |
White |
Mounting type |
Ceiling/wall |
International Protection (IP) code |
IP66 |
Housing material |
Aluminium |
Camera |
White balance |
ATW, AWC, Indoor, Manual, Outdoor |
Camera shutter speed |
1/5 – 1/12000 s |
Lens viewing angle, horizontal |
187° |
Lens viewing angle, vertical |
187° |
Lens viewing angle, diagonal |
187° |
Image sensor |
Sensor type |
CMOS |
Optical sensor size |
25.4 / 2.3 mm (1 / 2.3″) |
Number of sensors |
1 |
Lens system |
Number of lenses |
1 |
Maximum aperture number |
2.2 |
Closest focusing distance |
0.5 m |
Fixed focal length |
1.08 mm |
Night vision |
Night vision |
Yes |
Night vision distance |
10 m |
LED type |
IR |
Video |
Noise reduction |
Yes |
Privacy masking |
Yes |
Flip & mirror |
Yes |
Highlight Compensation (HLC) |
Yes |
Back Light Compensation (BLC) |
Yes |
Video compression formats |
H.264,H.265 |
Maximum resolution |
3008 x 3008 pixels |
Frame rate |
30 fps |
Video streaming |
Yes |
Total megapixels |
12 MP |
Network |
Bluetooth |
No |
Ethernet interface type |
Fast Ethernet |
Networking standards |
IEEE 802.1x,IEEE 802.3af |
Number of users |
20 user(s) |
Streaming method |
Multicast, Unicast |
Ethernet LAN |
Yes |
Wi-Fi |
No |
Supported network protocols |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP |
Storage |
Maximum memory card size |
512 GB |
Card reader integrated |
Yes |
Built-in HDD |
No |
Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Internal memory |
4096 MB |
Flash memory |
512 MB |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
1 |
Connectivity technology |
Wired |
Security |
Video motion detection |
Yes |
IP address filtering |
Yes |
HTTPS encryption |
Yes |
Anti-flicker |
Yes |
Power |
Power source type |
DC, PoE |
Power consumption (max) |
9.1 W |
Power consumption (Power over Ethernet (PoE)) |
11 W |
DC output voltage |
12 |
Operational conditions |
Operating temperature (T-T) |
-40 – 60 °C |
Storage temperature (T-T) |
-50 – 60 °C |
Operating relative humidity (H-H) |
0 – 95% |
Storage relative humidity (H-H) |
0 – 95% |
Weight & dimensions |
Height |
72 mm |
Diameter |
16 cm |
Weight |
1.1 kg |
Packaging content |
Number of cameras |
1 |
Other features |
Video compression formats |
H.264,H.265 |
