APC Smart-UPS uninterruptible power supply (UPS) Line-Interactive 2200 VA 1980 W 10 AC outlet(s)

SKU: SMX2200HV Category:

APC Smart-UPS uninterruptible power supply (UPS) Line-Interactive 2200 VA 1980 W 10 AC outlet(s)

* Images are for illustrative purposes only.

SHARE

Share on facebook
Share on twitter
Share on whatsapp
Share on reddit
Share on linkedin
Share on email

£1,322.18 £1,101.82 Ex. VAT

Availability: 9 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

Smart-UPS,1980 Watts /2200 VA,Input 230V, 230V /Output 230V, Interface Port SmartSlot, USB, Extended runtime model, Rack Height 4 U

Includes: CD with software, Rack Mounting brackets, Smart UPS signalling RS-232 cable, USB cable, User Manual


Feature Feature Value
UPS topology Line-Interactive
Output power capacity 2200 VA
Output power 1980 W
Waveform Sine
Input operation voltage (min) 140 V
Input operation voltage (max) 280 V
Input frequency 50/60 Hz
Output operation voltage (min) 208 V
Output operation voltage (max) 240 V
Output frequency regulation 50/60 Hz
Automatic Voltage Regulation (AVR) Y
Surge energy rating 645 J
Hold time (min) 2 ms
Hold time (max) 10 ms
Efficiency 98.1%
Emergency Power Off (EPO) Y
Noise level 55 dB
Surge protection Y
Audible alarm(s) Y
Auto-restart Y
AC outlet types C13 coupler,C19 coupler
Power plug IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
AC outlets quantity 10 AC outlet(s)
Number of output IEC jumpers 2
USB port Y
SmartSlot Y
Battery technology Sealed Lead Acid (VRLA)
Battery capacity 702 VAh
Typical backup time at full load 9.8 min
Typical backup time at half load 25.3 min
Battery life (max) 5 year(s)
Battery recharge time 3 h
Hot-swap battery Y
Automatic battery test Y
Cold start Y
Form factor Rackmount/Tower
Product colour Black,Stainless steel
Rack capacity 4U
Cable length 2 m
LED indicators Status,Battery replacement
Display LCD
RoHS compliance Y
Certification CE, CSA, EAC, EN 50091-1, EN 50091-2, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 CL A, IEC 60950, IRAM, RCM, UL 1778, VDE, WEEE, REACH
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -15 – 45 °C
Operating relative humidity (H-H) 0 – 95%
Storage relative humidity (H-H) 0 – 95%
Operating altitude 0 – 3000 m
Non-operating altitude 0 – 15000 m
Width 178 mm
Depth 483 mm
Height 432 mm
Weight 38.6 kg
Rack mount kit Y
Cables included RS-232,USB cable
Temperature sensor Y
Manual Y
Quick installation guide Y
Software CD Y
Package width 586 mm
Package depth 633 mm
Package height 330 mm
Package weight 47.7 kg
Quantity per pallet 6 pc(s)
Packaging content Web/SNMP Management Card
UPS topology

Line-Interactive

Efficiency

98.1%

Noise level

55 dB

USB port

Y

Hot-swap battery

Y

Cable length

2 m

Display

LCD

Weight

38.6 kg

Emergency Power Off (EPO)

Y

Surge protection

Y

SmartSlot

Y

Form factor

Rackmount/Tower

Rack capacity

4U

Width

178 mm

Rack mount kit

Y
