APC Smart-UPS On-Line uninterruptible power supply (UPS) Double-conversion (Online) 5000 VA 4500 W 10 AC outlet(s)


APC Smart-UPS On-Line uninterruptible power supply (UPS) Double-conversion (Online) 5000 VA 4500 W 10 AC outlet(s)

* Images are for illustrative purposes only.

£4,540.54 £3,783.78 Ex. VAT

Free UK Shipping Available*

Availability: 22 in stock

Finance/leasing available for orders over £1000 Inc VAT

Free mainland UK shipping on orders over £150 Ex VAT

APC Smart-UPS On-Line,4500 Watts /5000 VA,Input 230V /Output 230V, Interface Port Contact Closure, RJ-45 Serial, Smart-Slot, USB, Extended runtime model

Includes: Documentation CD, Installation guide, Rack Mounting brackets, Rack mounting hardware, Rack Mounting support rails, Temperature Probe, Warranty card

Feature Feature Value
UPS topology Double-conversion (Online)
Output power capacity 5000 VA
Output power 4500 W
Waveform Sine
Input operation voltage (min) 100 V
Input operation voltage (max) 275 V
Input frequency 40 – 70 Hz
Output operation voltage (min) 220 V
Output operation voltage (max) 240 V
Output frequency regulation 50/60 Hz
Surge energy rating 480 J
Efficiency 94.1%
Crest factor 3:1
Emergency Power Off (EPO) Y
Output voltage Total Harmonic Distortion (THD) 3%
Noise level 55 dB
Surge protection Y
Audible alarm(s) Y
Auto-restart Y
AC outlet types C13 coupler,C19 coupler
Power plug Terminal
AC outlets quantity 10 AC outlet(s)
Number of output IEC jumpers 2
USB port Y
Serial interface Y
Serial interface type RJ-45
SmartSlot Y
Battery technology Sealed Lead Acid (VRLA)
Battery capacity 845 VAh
Typical backup time at full load 4 min
Typical backup time at half load 11.8 min
Battery life (max) 5 year(s)
Battery recharge time 1.5 h
Hot-swap battery Y
Automatic battery test Y
Cold start Y
Replacement battery cartridge APCRBC140
Form factor Rackmount
Product colour Black
Rack capacity 3U
Display LCD
Energy Star certified Y
RoHS compliance Y
Certification REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -15 – 45 °C
Operating relative humidity (H-H) 0 – 95%
Storage relative humidity (H-H) 0 – 95%
Operating altitude 0 – 3000 m
Non-operating altitude 0 – 15000 m
Width 432 mm
Depth 719 mm
Height 130 mm
Weight 54.4 kg
Rack mount kit Y
Temperature sensor Y
Quick installation guide Y
Warranty card Y
Package width 610 mm
Package depth 960 mm
Package height 330 mm
Package weight 66.9 kg
Quantity per pallet 6 pc(s)
Packaging content Web/SNMP Management Card
UPS topology

Double-conversion (Online)



Rack mount kit


Surge protection



432 mm

Serial interface





54.4 kg

Energy Star certified


Hot-swap battery


Rack capacity


Form factor




USB port


Noise level

55 dB

Emergency Power Off (EPO)


Warranty card
